Flux Liquid Meter / Flowmeter
FMC Material Stainless Steel
The flow meters FMC work on the nutating disc principle. The liquid flow actuates the nutating disc. A Reed sensor is embedded in the disc. The number of rotation is counted and evaluated by the Fluxtronic.
Advantages
High accuracy
High resistance
Able to handle a small amount of solids suitable for hazardous area
Display flow amount and totalized
Batch control capability
For media
Pharmaceutical media
Cosmetic fluids
Food product liquids
Flammable liquids
Formic Acid
Specification
Protection class IP54
Flow rate 10-100 / 25-250 l/min
Accuracy +/- 1%
Repeatability +/- 0.15%
Viscosity 2,500 mPas
