Booster System
Booster Pump Unit consists of vertical multistage centrifugal pump,
pressure tank and control cabinet. A Booster Pump Unit can consist
of one to four pumps. The Booster Pump unit is designed to maintain
constant pressure pumping system. High quality standard piping systems
are incorporated to ensure trouble free operation.
Boiler Feed Pump
Speck Boiler Feed Pump is a horizontal multistage modular pump.
Designed for delivery and circulation of clear or slightly contamimated
water. Pump shaft bearing is with two external rolling bearings. Pump
impellers are hydraulically balanced impellers. Pump is available with
stuffing box packing or mechanical seal. Norminal pressure is PN40 and PN63.
Vacuum Pump
Speck liquid ring vacuum pumps are world well-known for high
quality and reliability. Pumps are available in cast iron, bronze and
stainless steel material. Pump in closed coupled version and base plate
version are standard. Accessories for vacuum pump such as separator,
heat exchanger, ejector, drain valve, vacuum check valve are available.
Vacuum System
A vacuum Unit consists of vacuum pump, liquid separator, heat exchanger,
and control cabinet. Speck vacuum pumps according to the liquid ring principal
are mainly used for the vacuum unit. A unit can consist of one or two pumps with
capacity up to 3,200 m3/h. Gas ejectors are available for increased vacuum.
Control cabinet with PLC is standard.
Thermal Oil Pump
Thermal Oil Pump is developed for circulating organic or synthetic heat transfer
oil in heat transfer systemin accordance with DIN 4754, as well as hot water.
Suitable for use with oil up to 350 degree C and hot water up to 160 degree C.
Nominal Pressure is PN16, casing material is available with Spheroidal graphite iron
and stainless steel. High energy efficient with highly efficient impellers.
